Liquid series

SP-203L / SP-204L

Vertical Form-Fill-Seal Machine for Liquid

powder-packaging-machine, liquid-packaging-machine
  • Applicable Packaging Products

    For packaging liquid and paste products. such as shampoo, ketchup, jelly, toothpaste, cream, honey etc.

  • Features
    1. This machine is ideal for packaging various liquid products.

    2. Employs German photocell sensor for accurate control of bag length.

    3. Employs Japanese thermostat for fast heating and superior performance.

    4. The parts through which liquid flow are manufactured from stainless steel or Teflon, conform to sanitation standards.

    5. Convenient, fast adjustment to suit various bag lengths.

    6. Accurate volume filling achieved by precise piston pump.

    7. Built with anti-drip device to prevent contamination by sticky flow of material.

powder-packaging-machine, liquid-packaging-machine

P

r

o

d

u

c

t

s

Specifications

Model SP-203L SP-204L
Bag Shaper 3-Side 4-Side
Film Width 60 - 160 mm
Bag Width 30 - 80 mm
Bag Length 50 - 120 mm
Packaging Speed 40 - 80 bags/min
Volume Range 2 - 30 ㏄
Hopper Capacity 20 L
Power Source AC 110V 220V, 50/60Hz
Power Consumption 1.35 KW
Machine Dimensions 1000x600x1750mm
Case Dimensions 1100x700x1900mm
Machine Weight 320 kgs
Shipping Weight 430 kgs

* All specifications are subject to change without prior notice.
